Fumei MT27 Narrow Thermal Break Sliding Door

Fumei MT27 Narrow Thermal Break Sliding Door

A sliding door is a door that opens by sliding horizontally. Sliding doors can be mounted on top of a lower track or hung from an upper track.

Quantity:
Availability:





Inquire Add to Basket

Product Description

Product Advantage

Product Details

Product Configuration

FAQ

Product Description

Water Tightness Performance

Air Tightness Performance

Wind Pressure Resistance Performance

Soundproofing Performance

Thermal Insulation
Performance

Level 6

Level 4

Level 9

≥33dB

K≤2.5

A sliding door is a door that opens by sliding horizontally. Sliding doors can be mounted on top of a lower track or hung from an upper track.

Product Advantage

	27mm ultra-narrow middle frame design,multiple sashes open to an oversized size
	High-quality anti-swing wheels,smoother sliding
	High waterproofrail + hidden drainage design,preventingrainwater backflow
	Super national standard profile thicknessfearless against strong wind and rain
	48-mesh high-transparency screen net,wide field of view, mosquito-proof

Product Details

Product Configuration

Product Configuration	Specifics
Frame Structure	Thermal Break, Frame-over-Sash Structure
Thermal Barrier	Frame C14.8mm, Sash 14.8mm
Visible Width	Frame 52mm, Meeting Stile 27mm
Opening Method	Double Track Double Sash Double Track Quad Sash Triple Track Double Sash with Screen Triple Track Quad Sash with Screen
Glazing	5+15A+5
Hardware	Standard Fuson Custom Hardware, Optional Hoppe Lift & Slide Hardware
Screen Mesh	Standard HD Fiberglass Mesh, Optional: Ultra-Clear Mesh Stainless Steel Security Mesh Woven Mesh
Wall Occupation Depth	Double Track: 135mm Triple Track: 189mm
Profile Thickness	Main Frame: 1.8-2.2mm Glazing Sash: 1.7-2.2mm Screen Sash: 1.8mm

FAQ

Q1: Are you a factory ?

A:Yes, our production base covers an area of 560,000 square meters, nearly 20 years of industry experience, and the top five well-known brands in China.

Q2: Are your products certified ?

A:Yes, it has complete international certification and test report, including Australian standard, European standard, American standard and so on.

Q3:Can doors and windows be customized ?

A:Yes, to meet the specific use of the environment of high custom and provide aluminum doors and windows matching the style of the building.

Q4: What's your MOQ?

A:We don't enforce strict MOQ requirements, allowing flexible order quantities. However, please note that smaller orders may incur proportionally higher shipping costs. For your reference, we always provide transparent cost breakdowns separating product value and shipping expenses.

Q5: Do you provide after-sales service ?

A:Quality and after-sales are guaranteed, any problem contact us.
